RF Modules for OEM's and Intelligent Rack Systems Capable of Monitoring from Around the World
You have a wide variety of functions and features available when choosing amplifiers from Empower RF Systems that go well beyond varieties of power and bandwidth. Designed for uncompromising RF performance and mechanical "ease of use", these products come standard with control and protection features that insure over temperature performance and reliable operation.
Many of our popular modules include Adjustable gain, Standby Mode, Temperature Sensing, and all include Current Limit, Reverse Polarity, and Temperature Protections. For the RF system designer we offer modules easily combinable with our RS485 interface that makes each module addressable for monitoring and control, allowing you faster time to market while delivering a more robust system to your customers.
Broadband and band specific variations of these products are available up to 6 GHz and in various gain / output power configurations. The full array of frequency and power combinations available with these building block modules can be viewed by accessing the Module tabs on our website www.empowerrf.com.
Download our corporate catalog.
High Power Compact Building Block Modules |
| SKU 1061 |
25 W |
1-250 MHz |
6.4 x 3.4 x 1.1" |
| SKU 1094 |
100 W |
20-520 MHz |
6.4 x 3.4 x 1.1" |
| SKU 1163 |
125 W |
20-520 MHz |
7.0 x 4.0 x 1.2" |
| SKU 1100 |
80 W |
20-1000 MHz |
6.4 x 3.4 x 1.1" |
| SKU 1193 |
100 W |
20-1000 MHz |
7.0 x 4.0 x 1.2" |
| SKU 1166 |
200 W |
20-1000 MHz |
7.2 x 7.6 x 1.2" |
| SKU 1203 |
200 W |
500-2000 MHz |
10.0 x 6.0 x 1.1" |
| SKU 1119 |
50 W |
500-2500 MHz |
7.4 x 3.6 x 1.1" |
| SKU 1189 |
100 W |
500-2500 MHz |
7.4 x 3.6 x 1.06" |
| SKU 1208 |
100 W |
500-2700 MHz |
8.2 x 3.6 x 1.06" |
| SKU 1164 |
50 W |
800-3000 MHz |
6.4 x 3.4 x 1.1" |
| SKU 1199 |
100 W |
1000-3000 MHz |
7.0 x 4.0 x 1.1" |
| SKU 1184 |
15 W |
700-3800 MHz |
6.0 x 3.0 x 1.0" |
| SKU 1131 |
35 W |
2500-6000 MHz |
6.9 x 3.6 x 1.1" |
| SKU 1191 |
100 W |
2500-6000 MHz |
8.0 x 6.5 x 1.0" |
|
SKU 1191
2500-6000 MHz, 100 W
7 x 4 x 1.2"
Adjustable Gain, RS485 for Control and Monitoring
SKU 1166
20-1000 MHz, 200 W
7.2 x 7.6 x 1.2"
Big Power in a Small Package
SKU 1205
500-2700 MHz, 25 W
8.2 x 3.6 x 1.06"
Built in Temp Sensor with Standby on/off Control
SKU 1189
500-2500 MHz, 100 W
7.4 x 3.6 x 1.06"
Built in Temp Sensor with Standby on/off Control
SKU 1094
20-520 MHz MHz, 100 W
6.4 x 3.4 x 1.06"
Fast switching/mute function, Gain adjustable
|
Rack Mount High Power Amplifier Systems
For sophisticated end users who need big power and remote monitoring and control then our patented Next Generation power amplifiers are for you, allowing the user to initiate remote management and diagnostics via an embedded web server, enabling network managed site status and control simply by connecting the unit’s Ethernet port to a LAN or via Wi-Fi by adding a wireless router. For machine to machine interface (M2M), these system amplifiers offers TCP/IP or UDP protocol sockets accessed through the Ethernet port. To learn more about these smart amplifier systems, download Next Generation Systems Flyer.
|
